Limited Edition Original Eachine Wizard TS215 FPV Racing RC Drone

Wheelbase: 215mm

Material: 3K carbon fiber

Frame arm thickness: 4mm
Top plate thickness: 3mm
Bottom plate thickness: 3mm

Artist: hydrographics transfer printing

Version: RTF

BEC: no

Continuous current: 40A

Peak current (5S): 45A

Input voltage: 3-5S

Current sensor: built in

LED indicator onboard, the light colors are adjustable.

Supports Dshot1200, Dshot600, Dshot300, Dshot150.

KV: 2450

NO.OF cell: 2-6S

Thrust: 2300g (16V 6040 2-blade prop)

Framework: 12N14P

Motor shaft: 5mm

Weight: 32.5g

CPU: f4STM32 F405 SCM

Barometer: BMP280

Input voltage: 3-5S

Sensor: MPU6000 SPI

With SD slot

Built in OSD

Built in 5V 3A BEC

Input voltage: 7-24V

Extra features: smart audio, 0.01mW (parameter-adjusting mode)

Power supply: 5V camera @ under 0.3A max.

Output voltage: 25mW-100mA 200mW-200mA 500mW-260mA 800mW-300mA @ 12V

Range: up to 4km with omnidirectional RHCP antennas

Antenna connector: MMCX, RP-SMA

Port connector: JST, 4pin

Dimensions: 30.5×30.5mm

Weight: 8.5g (excluding antenna)

Material: 128g double copper

Adjustable 25mw / 200mw / 500mw / 800mw

Supports smart audio (remote parameter adjustment)

Image sensor: 1/3″ SONY Super HAD II CCD

Horizontal resolution: 600TVL, 4:3

Lens: 2.3mm 150°

Signal system: PAL

Integrated OSD: YES

Integrated MIC: YES

S/N Ration: >60dB(AGC OFF)

Electronic shutter speed: PAL:1/50~100,000

AutoGain control(AGC): YES

Back light compensation(BLC): YES

Min.illumination: 0.01Lux/1.2F

WDR: D-WDR

DNR: 2DNR

Day/Night: Color / Auto / B&W

Power: DC 5 to 36V

Net weight: 14g

Dimensions: 28.5mm * 26mm * 26mm

Connector: JST-XH 1.25mm * 5P/2P

Dimension: 21.5*12*3.5mm(L x W x H)

Weight: 1.6g

Number of channels: up to 16CH from SBUS (1-15ch for PWM,16ch RSSI for FC)

Operating voltage range: 3.7~10V

Operating current: 30mA @5V

Operating range: full range

With RSSI output on board: analog 0~3.3V

Firmware upgradeable

Compatibility: FrSky D16 mode

Color: black

Number of channels: 16 channels

Weight: 308g

Operating voltage Range: 6.0 ~ 8.4V

Operating current: 190mA@7.4V

Operating temperature: -20 ~ 60℃

Backlight LCD resolution: 128*64

Model Memory: 60 models (extendible by Micro/TF card)

Ergonomic and compact design

M12 Lite gimbal

Digital high accuracy hall sensor gimbal

Mode conversion adjustments accessible without disassembly

CNC machined gimbal pedestal

High-speed internal and external module digital interface

Internal: 450K, External: 420K

Super low latency (Total latency < 20ms, lowest to 12ms)

Compatible with new lite type external modules (R9M Lite, MPM Lite, etc.)

Installed open source operating system– OpenTX

Haptic vibration alerts and voice speech outputs (Headset jack and inbuilt speaker)

Internal antenna and external antenna connector

128*64 outdoor readable backlight LCD

Smart Port, Micro USB-B Port, Headset jack and TF card slot

The easily accessible battery compartment uses replaceable 18500 Li-ion batteries (Batteries Not Included)

Wireless function (Optional)

Compatible with FrSky Free Link App

Support wireless trainer system

(Need additional parts or order specific model)

CPU: ARM926EJ-S–402MHz

Flash: 16Mb

Video resolution: NTSC:720×480; PAL:720×576

Video code model: H.264

Forms of video file: .AVI

Every video time: 15 minutes

Memory capacity: Max 32G (Class10)

Size: 36x36mm

Support power voltage: 4.5~5.5V

Maximum operating current: 300mA

Operating temperature: 0~+45 ℃

Operating humidity: 15%~85% RH

Storage temperature: –20~+50 ℃

Storage humidity: 10%~90% RH

Size: 5046 5×4.6

Mounting hole: 5mm

Color: blue and transparent white

Capacity(mah): 1550

Cell(s): 5

Voltage(V): 18.5

Discharge Rate(C): 80
